Gasket for universal uses – ideal for thermal solar applications and high temperature.
| codice | descrizione | pz conf. |
| 1774GES31 | 3/8 ridotto mm 13,5×8,5×2 | 100 |
| 1774GES32 | 3/8 mm 14,5x9x2 | 100 |
| 1774GES33 | 1/2 mm 18,5x11x2 | 100 |
| 1774GES34 | 3/4 normale mm 24x18x2 | 100 |
| 1774GES35 | 3/4 speciale mm 24x16x2 | 100 |
| 1774GES36 | 1” normale mm 30x24x2 | 100 |
| 1774GES37 | 1” speciale mm 30x21x2 | 100 |
| 1774GES38 | 1” 1/4 mm 38,5x30x2 | 100 |
| 1774GES39 | 1” 1/2 mm 44,5x36x2 | 100 |
| 1774GES39A | 2” mm 56×43,5×2 | 100 |
Fasit 202 sanitary gaskets.
| code | description | pcs per pack |
| 1774GES54 | 1/4 mm 10,7x6x2 | 100 |
| 1774GES01 | 3/8 mm 14,5x9x2 | 100 |
| 1774GES02 | 1/2 mm 18,5x11x2 | 100 |
| 1774GES04A | 3/4 NORMALE mm 24x18x2 | 100 |
| 1774GES04 | 3/4 speciale mm 24x16x2 | 100 |
| 1774GES04B | 3/4 speciale mm 24x16x3 | 100 |
| 1774GES05 | 1” normale mm 30x24x2 | 100 |
| 1774GES06 | 1” speciale mm 30x21x2 | 100 |
| 1774GES07 | 1” 1/4mm 39x30x2 | 100 |
| 1774GES08 | 1” 1/2mm 44,5x36x2 | 100 |
| 1774GES09 | 2” mm 56×43,5×2 | 100 |
| 1774GES09A | 2” 1/2 mm 61,5x47x2 | 100 |
Gasket for sanitary fittings. Suitable for potable water, gas, oils and fuels.
| codice | descrizione | pz conf. |
| 1774GES46A | 3/8 14,6X9X2 | 100 |
| 1774GES46B | 1/2 18,5X11X2 | 100 |
| 1774GES46C | 3/4 normale 24X18X2 | 100 |
| 1774GES46D | 3/4 speciale 24X16X2 | 100 |
| 1774GES46DA | 3/4 speciale 24X14,5X2 | 100 |
| 1774GES46E | 1″ normale 30X24X2 | 100 |
| 1774GES46F | 1″ speciale 30X21X2 | 100 |
| 1774GES46G | 1″1/4 39X30X2 | 100 |
| 1774GES46H | 1″1/2 44,5X36X2 | 100 |
| 1774GES46I | 2″ 56X44X2 | 100 |
Gaskets resistant to high temperatures and dynamic loads. Contains lamellar graphite.
| codice | descrizione | pz conf. |
| 1774GES43 | 3/8 14,5x9x2 | 100 |
| 1774GES44 | 1/2 18,5x11x2 | 100 |
| 1774GES45 | 3/4 specile MM 24X14,5X2 | 100 |
| 1774GES45A | 1 speciale 30x21x2 | 100 |
| 1774GES45AB | 1″1/4 39X30X2 | 100 |
| 1774GES45AC | 1″1/2 44,5X36X2 | 100 |
| 1774GES45AD | 2″ 56X44X2 | 100 |
Gold Gasket: soft and flexible.
| codice | descrizione | pz conf. |
| 1774GGA01C | 3/8″ MM 14,6X9X2 | 100 |
| 1774GGA02C | 1/2″ MM 18,5X11X2 | 100 |
| 1774GGA03B | 3/4 normale MM 24X18X2 | 100 |
| 1774GGA04B | 3/4 speciale MM 24X16X2 | 100 |
| 1774GGA05B | 1″ normale MM 30X24X2 | 100 |
| 1774GGA06A | 1″ speciale MM 30X21X2 | 100 |
| 1774GGA07B | 1″1/4 MM 38,6X30X2 | 100 |
| 1774GGA08B | 1″1/2 MM 44,5X36X2 | 100 |
| 1774GGA09A | 2″ MM 56X44X2 | 100 |
Mecsint red fibre.
| codice | descrizione |
| 1774GIF02a | 3/8 mm 14,5x9x2 |
| 1774GIF02 | 1/2 mm 18,5x11x2 |
| 1774GIF15 | 3/4 normale mm 24x18x2 |
| 1774GIF16 | 3/4 speciale mm 24x16x2 |
| 1774GIF16A | 3/4 speciale mm 24×14,5×2 |
| 1774GIF17 | 1” normale mm 30x24x2 |
| 1774GIF18 | 1” speciale mm 30x21x2 |
| 1774GIF19 | 1” 1/4 mm 38,5x30x2 |
| 1774GIF20 | 1” 1/2 mm 44,5x36x2 |
Vulkanite red fibre.
| codice | descrizione |
| 1774GIF21 | 3/8 mm 14,5x9x2 |
| 1774GIF22 | 1/2 mm 18,5x11x2 |
| 1774GIF23 | 3/4 normale mm 24x18x2 |
| 1774GIF24 | 3/4 speciale mm 24x16x2 |
| 1774GIF24A | 3/4 speciale mm 24×14,5×2 |
| 1774GIF25 | 1” normale mm 30x24x2 |
| 1774GIF26 | 1” speciale mm 30x21x2 |
| 1774GIF27 | 1” 1/4 mm 38,5x30x2 |
Rubber washers for sanitary.
ON DEMAND ALSO AVAILABLE IN NBR – NBR GAS – WHITE RUBBER…
| codice | descrizione | pz conf. |
| 1774TBG01 | 3/8 14,5 x 10 x 2 mm | 100 |
| 1774TBG01A | 3/8 14,5 x 8 x 2 mm | 100 |
| 1774TBG01B | 3/8 14,5 x 8 x 3 mm | 100 |
| 1774TBG01C | 3/8 14,5 x 12 x 3 mm | 100 |
| 1774TBG02 | 1/2 mm 18.5 x 10 x 2 foro 10mm | 100 |
| 1774TBG02A | 1/2 mm 18,5 x 12 x 2 foro 12 mm | 100 |
| 1774TBG02B | 1/2 mm 18,5 x 14 x 3 foro 14 mm 3 | 100 |
| 1774TBG02C | 3/4 mm 24 x 14 x 2,5 | 100 |
| 1774TBG03 | 3/4 mm 24 x 16 x 2 | 100 |
| 1774TBG04 | per tubo lavatrice 3/4 mm 24 x 16 x 2.5 | 100 |
| 1774GGM11 | 1” normale mm 30 x 24 x 2 | 100 |
| 1774GGM12 | 1” speciale mm 30 x 21 x 2 | 100 |
| 1774GGM13 | 1” 1/4 mm 39 x 30 x 2 | 100 |
| 1774GGM14 | 1” 1/2 mm 44 x 36 x 2 | 100 |
| 1774GGM14A | 2” mm 56 x 44 x 2 | 100 |
| Altre dimensioni disponibili in Gomma EPDM 80SH. Spessore su richiesta. Minimo quantitativo ordinabile: 1000 pz. |
|||
| 8,5×6 | 12,3×8,4 | 16×11 | 20×14 |
| 9,5×5,5 | 13,8×9,2 | 18×10 | 20,8×15 |
| 10,6×7,8 | 14,3×9,2 | 18,5×13 | 23,5×17 |
| 11,6×8,1 | 14,5×10,7 | 19×11 | 24×11 |
SBR 70SH rubber Gasket for aerator.
| codice | descrizione | pz conf. |
| 1774GGM26 | mm 21 x 14 x 2 | 100 |
| 1774GGM27 | mm 21 x 15 x 2 | 100 |
| 1774GGM28 | mm 21 x 16 x 2 | 100 |
| 1774GGM29 | mm 22 x 15 x 2 | 100 |
| 1774GGM30 | mm 22 x 16 x 2 | 100 |
Rubber seats.
| codice | IN gomma epdm conforme FDA descrizione |
pz conf. |
| 1774TBG07 | 3/8 14 x 4 x 4 | 100 |
| 1774TBG08 | 1/2 16 x 4 x 4 | 100 |
| 1774TBG10 | 3/4 24 x 4 x 4 | 100 |
| Altre dimensioni disponibili in Gomma EPDM Conforme FDA 80SH su richiesta. Minimo quantitativo ordinabile: 1000 pz. |
||
| 1774TBG11 10 x 4 x 4 | 1774TBG19 16 x 5 x 4 | 1774TBG27 tappo 12 x 4 |
| 1774TBG12 10 x 4 x 5 | 1774TBG20 16 x 6 x 4 | 1774TBG28 tappo 13 x 4 |
| 1774TBG13 11 x 4 x 4 | 1774TBG21 17 x 4 x 4 | 1774TBG29 tappo 14 x 4 |
| 1774TBG14 12 x 4 x 4 | 1774TBG22 17 x 5 x 4 | 1774TBG30 tappo 15 x 4 |
| 1774TBG15 12 x 4 x 5 | 1774TBG23 17 x 6 x 4 | 1774TBG31 tappo 16 x 4 |
| 1774TBG16 13 x 3 x 4 | 1774TBG24 18 x 4 x 4 | 1774TBG32 tappo 17 x 4 |
| 1774TBG17 13 x 4 x 4 | 1774TBG25 tappo 10 x 4 | 1774TBG33 tappo 18 x 4 |
| 1774TBG18 15 x 4 x 4 | 1774TBG26 tappo 11 x 4 | 1774TBG34 tappo 18 x 5 |
| codice | IN gomma tenax 85/90 SH
Minimo quantitativo ordinabile: 1000 pz. |
pz conf. |
| 1774GTX01 | 3/8 mm 14,5 x 5 x 4 | 100 |
| 1774GTX02 | mm 21 x 6 x 4 | 100 |
| 1774GTX04 | 3/4 mm 24 x 6 x 4 | 100 |
| 1774GTX05 | mm 26 x 6 x 4 | 100 |
| 1774GTX06 | 1” mm 28 x 6 x 4 | 100 |
| Altre dimensioni disponibili in Gomma Tenax 85/90 SH su richiesta. Minimo quantitativo ordinabile: 1000 pz. |
||
| 1774GTX07 14 x 6,5 x 4 | 1774GTX10 20 x 4 x 4 | 1774GTX13 23 x 8 x 4
1774GGM06 Tappo 23 x 4 |
| 1774GTX08 16 x 8 x 4 | 1774GTX11 20 x 5 x 4 | 1774GTX14 28 x 8 x 4
1774GGM07 Tappo 28 x 4 |
| 1774GTX09 19 x 5 x 4 | 1774GTX12 22 x 6 x 4 | |
| codice | IN SILICONE descrizione |
pz conf. |
| 1774SIL01 | 3/8 mm 14 x 4 x 4 | 100 |
| 1774SIL02 | 1/2 mm 16 x 4 x 4 | 100 |
Disponibili dimensioni per contatori acqua. Richiedi quotazione qui.
PVC conical.
| codice | descrizione | pz conf. |
| 1774pvc01 | 3/8 foro 10 mm | 100 |
| 1774pvc02 | 1/2 foro 10 mm | 100 |
| 1774pvc03 | 1/2 foro 12 mm | 100 |
| 1774pvc04 | 1/2 foro 14 mm | 100 |
| 1774pvc05 | 3/4 mm 22 x 16 x 7 | 100 |
| 1774pvc06 | 1” mm 30 x 24 x 7 | 100 |
| 1774pvc07 | 1” mm 30 x 26 x 7 | 100 |
| 1774pvc09 | 1” 1/4 mm 37 x 32 x 7 | 100 |
| 1774pvc10 | 1” 1/2 mm 45 x 40 x 7 | 100 |
Conical seal in black NR rubber.
| codice | descrizione | pz conf. |
| 1162gst82 | Ø 10 – 3/8 | 100 |
| 1162gst83 | Ø 10 – 1/2 | 100 |
| 1162gst84 | Ø 12 – 1/2 | 100 |
| 1162gst84A | Ø 14 – 1/2 per cannucce / for thin canes | 100 |
| 1162gst77 | Ø 18 | 100 |
| 1162gst86 | Ø 24 – 26 | 100 |
| 1162gst78 | Ø 30 | 100 |
| 1162gst79 | Ø 32 | 100 |
| 1162gst80 | Ø 40 – 45 | 100 |
| 1162gst81 | Ø 45- 50 | 100 |
| 1162gst87 | Ø 40 x 32 | 100 |
| 1162gst88 | Ø 40 x 35 per cannotti / for thin canes | 100 |
Santoprene rubber washer with Inox mesh insert.
Dimensions: 3/8” mm – 1/2” mm – 3/4” mm – 1” mm.
Plan or rounded Inox mesh, on demand.
| codice | Dimensioni |
| 1774gst84 | 3/8″ mm 14 x 10 x 2,1 |
| 1774gst84a | 3/8″ bombata mm 15 x 10 x 1,8 |
| 1774gst82 | 1/2″ mm 18 x 14,5 x 2,5 |
| 1774gst83b | 3/4″ mm 24 x 17,5 x 3,2 |
| 1774gst85 | 1″ mm 30 x 22 x 3,2 |
Vulkollan gaskets 60SH 70SH 80SH 90 SH.
Gasket for universal uses. Suitable for potable water, gas, oils and fuels. Ideal for thermal solar applications and high temperature.
| codice | descrizione | pz conf. |
| 1774GES32D | 3/8″ MM 14,5X9X2 | 100 |
| 1774GES33L | 1/2″ MM 18,5X11X2 | 100 |
| 1774GES34D | 3/4 normale MM 24X18X2 | 100 |
| 1774GES35C | 3/4 speciale MM 24X16X2 | 100 |
| 1774GES36A | 1″ normale MM 30X24X2 | 100 |
| 1774GES37D | 1″ speciale MM 30X21X2 | 100 |
| 1774GES38B | 1″1/4 MM 38,5X30X2 | 100 |
| 1774GES39B | 1″1/2 MM 44,5X36X2 | 100 |
| 1774GES39A | 2″ MM 56X43,5X2 | 100 |
